Titanium Alloy TC4
Material Properties of Titanium Alloy TC4
Surface roughness - sandblasted state | ≥ 7um |
Hardness (printing)/HRC | 38 ± 3 |
Hardness (after heat treatment)/HRC | 35 ± 3 |
Yield strength (printed)/MPa | 1050 ± 50 |
Yield strength (after heat treatment)/MPa | 950 ± 50 |
Elongation (printing)/% | 7 ± 3 |
Elongation (after heat treatment)/% | 13 ± 3 |
Tensile strength (printed)/MPa | 1230 ± 50 |
| Tensile strength (heat treatment)/MPa | 1015 ± 50 |
Material Characteristics and Disadvantages are Evaluated of Titanium Alloy TC4
Merit
This material can achieve high specific strength, light weight, high strength, long working temperature up to 400℃.
Shortcoming
The surface roughness of the product is high.
Application Area of Titanium Alloy TC4
The medical, automotive, aerospace, energy, marine, and sports equipment industries widely apply these materials to structural components that require high performance, high strength, low density, excellent corrosion resistance, and good biocompatibility. Examples include aircraft engine parts, fuselage structures, orthopedic implants (such as artificial joints, plates, screws), dental implants, customized surgical instruments, automotive engine components, suspension systems and exhaust systems, high-end bicycle frames, golf clubs, and mountaineering equipment.
